5054 WGRBWW 5in1 P1C series
Product Feature:
★Adopt well-known vender’s chip package.
★99.99% gold wire welding
★SMD substrates,good heat sink
★Good bright spots and High bright
Product Use:
★Stage Light,Decorative Light
★Fountain Light,Aquarium Light,etc
★Adopt well-known vender’s chip package.
★99.99% gold wire welding
★SMD substrates,good heat sink
★Good bright spots and High bright
Product Use:
★Stage Light,Decorative Light
★Fountain Light,Aquarium Light,etc
5054 WGRBWW 5in1 P1C series
?規(guī)格Datasheet
| 型號 Part No. |
功率 Power (W) |
波長WLD(nm) /色溫CCT(K) |
光通量 Luminous (lm) |
電壓 Voltage (V) |
電流 Current (mA) |
角度 Angle (deg) |
| JH-5054WGRBWW12J20 ?-P1C |
2.5 | 620-630nm | 15-25 | 2.0-2.4 | 150 | 120 |
| 515-525nm | 30-40 | 2.8-3.4 | 150 | |||
| 460-470nm | 5-15 | 2.8-3.4 | 150 | |||
| 6000-8000k | 70-90 | 2.8-3.4 | 150 | |||
| 2500-2700k | 70-90 | 2.8-3.4 | 150 |
Note: Customization is available upon request!
